Unbox Your Creativity

Box-Style Mirrorless Cinema & Live Camera supports unlimited C4K/4K 60p/50p and 4K 10-bit recording, Dual Native ISO, and 13 stops of dynamic range with V-Log L. Compact and easy to deploy, this flexible camera can be mounted on drones and in crash-boxes and scales seamlessly for multi-camera work thanks to PoE+, SDI/HDMI simultaneous output, and Genlock IN and Timecode IN/OUT.

SPECIFICATIONS

WEIGHT	Approx. 545 g / 1.2 lb (Body only)
SENSOR	Micro Four Thirds System
DIMENSIONS (W x H x D)	Approx. 93.0 x 93.0 x 78.0 mm / 3.66 x 3.66 x 3.07 inch (excluding protrusions)
LENS MOUNT	Micro Four Thirds mount
MEDIA SHOT	SD Memory Card / SDHC Memory Card^* / SDXC Memory Card^* *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
POWER CONSUMPTION	AC Adaptor (12 V, 3 A) (bundled) Li-ion Battery Pack (7.28 V) (sold separately) PoE+ (IEEE802.3at compliant) (sold separately)

SEE FULL SPECIFICATION

KEY FEATURES

10.2MP Live MOS Sensor with
Dual Native ISO Technology

Based on the Micro Four Thirds™ system standard and featuring a 10.2-megapixel Live MOS sensor, LUMIX BGH1 delivers professional-level image quality. The sensor features Dual Native ISO technology developed for Panasonic VariCam professional cinema-cameras and leverages a dual-base ISO setting that reduces noise while maximizing image quality from low to high sensitivity. The sensor partners with Venus Engine to deliver a maximum ISO 51200/Extended ISO 204800 for minimal noise at high sensitivity and more beautiful reproduction of dark areas in the frame. A low-pass filter effectively suppresses moiré. BGH1 meets demand for professional-level videography in low-light conditions.

The Micro Four Thirds™ name and logos are trademarks or registered trademarks of Olympus Corporation in Japan, the United States, the European Union, and other countries and regions.

Wide Dynamic Range of
13 Stops with V-Log L

V-Log L comes preinstalled for 13 stops of dynamic range. Users enjoy impressively accurate color reproduction with subtle gradations from dark areas to highlights. Since V-Log L has the same V-Gamut characteristics as V-Log, LUTs used with V-Log can also be used in color-grading and footage from VariCam series cameras can be included seamlessly in the edit.

Multiple Recording Modes

LUMIX BGH1 offers multiple recording modes used for cinema, broadcasting, and other professional applications. In addition to C4K/4K 60p/50p 4:2:0 10-bit, C4K/4K 30p/25p/24p 4:2:2 10-bit, and ALL-Intra 400 Mbps recording, anamorphic 4K recording is also supported with unlimited recording offered on all settings. This camera delivers the quality, flexibility, and creativity that professionals demand in the widest possible range of video production environments.

C4K/4K 60p 10-bit Internal/External
Simultaneous Recording

10-bit video-recording capability provides robust color-profiles for an advanced post-production workflow. LUMIX BGH1 offers simultaneous C4K/4K 60p/50p 4:2:0 10-bit internal recording and C4K/4K 60p/50p 4:2:2 10-bit live output for external recording via HDMI. This compact, lightweight camera offers all the quality you would expect from a high-end digital cinema-camera.

Heat Management
= Unlimited Recording

LUMIX BGH1 supports unlimited video recording in all modes. Drawing on technology developed for the LUMIX GH series, the exterior is designed for uniform heat dissipation. Aluminum and magnesium alloy body-frame and a cooling fan contribute to improved heat-dissipation efficiency while reducing weight for portability. Enjoy better durability and functionality from a compact body.

Remote Control with
LUMIX Tether for Multicam^*

LUMIX Tether for Multicam provides an astonishing amount of control for those wanting to broadcast video feeds into the encoding software of their choice. The software doesn’t limit you to one camera; you can take full control of multiple cameras tethered to your PC. Now there’s no need to physically go to each camera just to change a simple setting.

* LUMIX Tether for Multicam software will be released in the BGH1 product shipment.

A LUMIX First:
Ethernet/PoE+ Camera Compatibility

Simply connect the LUMIX BGH1 via Ethernet cable to power the camera over Ethernet^* and to enable multi-camera remote-control via LUMIX Tether for Multicam software.

* Ethernet is IEEE802.3at-compliant.

A LUMIX First:
Simultaneous SDI/HDMI Output

BGH1 meets the needs of professional videographers working in the widest range of video production situations and is the first LUMIX camera to feature an SDI (3G-SDI) terminal. The connection supports 1080p output, ensures stable connectivity over extended cable runs, and enables external monitoring. Simultaneous external recording via HDMI output and remote control via USB or LAN tethering deepen your video-production capabilities.

A LUMIX First:
Genlock IN and Timecode IN/OUT

With multi-camera control and live-streaming in mind, BGH1 delivers another LUMIX first with Genlock IN. When used in combination with timecode, the function facilitates high-precision editing. Synchronizing to the frame based on an external input signal, Genlock IN achieves perfect synchronization of multiple cameras for live sports and other challenging applications. Feeds connect seamlessly even when using a video switcher. Furthermore, timecode is embedded directly in the video for high-precision drone shooting and other single-camera shoots.

Other Special Features

LUMIX BGH1 has a diversity of features that address the needs of video-production professionals with high-quality image capture, intuitive operation, and seamless scalability.

Professional-level image quality
- 10x slow motion/30x quick motion
- 4K HDR video
- Autofocus featuring AI technology and more…

Superior operability during shoots
- Double SD card slot
- Bundled cable lock band and more…

Flexible deployment, control, and scalability
- Three power-source options
- Wi-Fi/Bluetooth/LUMIX Sync app and more…

SDK (Software Development Kit) for camera control via USB/Ethernet
SDK will be released for owners of compatible LUMIX cameras (BGH1, S1H, S1R, S1, S5, GH5S, GH5, and G9) at panasonic.jp/support/global/cs/soft/tool/sdk.html
