4K Uncompressed RAW up to 120 fps
with Codex V-RAW 2.0 Recorder
V-RAW for the best image quality and superior flexibility.
V-RAW supports 14+ stops wide-dynamic-range images out of a Super 35 mm native 4K sensor as RAW data.
Uncompressed 4K RAW signal up to 120 fps.
| Sensor Raster | 4K: 4096 x 2160 active pixels UHD: 3840 x 2160 active pixels |
|---|---|
| Recording Format | 12-bit/10-bit V-Log uncompressed V-RAW |
| System Frequency | 59.94p, 50p, 29.97p, 25p, 24p, 23.98p |
| Frame Rates | 12-bit: System Frequency only 10-bit: 1-120p at 59.94p, 29.97p, 24p, 23.98p 10bit: 1-100p at 50p, 25p |
V-RAW WORKFLOW: V-RAW
Codex V-RAW 2.0 Recorder handles uncompressed 4K resolution images at up to 120 fps. Recorded images can be de-bayered in VariCam and previewed. Offloading, previewing, and creating dailies are possible using Codex Vault, Capture Drive 2.0, and Codex Production Suite.
4K V-RAW for Your Best Image Quality and Creativity
V-RAW can be recorded onto Codex V-RAW 2.0 Recorder, which is dockable on the VariCam 35 (AU-V35C1) camera module.
PRODUCTS
Codex V-RAW 2.0 Recorder
RECORDING
Directly attach the Codex V-RAW 2.0 Recorder to the Panasonic VariCam 35 Camera module (AU-V35C1) for uncompressed RAW capture of full-frame 4K material at up to 120 fps. Fully compatible with industry-standard Codex workflow products.
KEY FEATURES
- Direct attachment to Panasonic VariCam 35 Camera module (AU-V35C1)
- Uncompressed 4K at up to 120 fps
- Codex Capture Drive® 2.0
- Industry Standard workflow and support via Codex Production Suite
Record times to Capture Drive 2.0
The table below details the record time available to Capture Drive 2.0 for the available formats:
| Resolution | Bit-Depth | Frame Rate | Record Time (Minutes) |
|---|---|---|---|
| 3840 x 2160 | 10-bit | 23.98/24 | 119 |
| 25 | 114 | ||
| 29.97/30 | 95 | ||
| 48 | 59 | ||
| 50 | 57 | ||
| 59.94/60 | 47 | ||
| 96 | 29 | ||
| 120 | 23 | ||
| 12-bit | 23.98/24 | 106 | |
| 25 | 101 | ||
| 29.97/30 | 84 | ||
| 4096 x 2160 | 10-bit | 23.98/24 | 112 |
| 25 | 107 | ||
| 29.97/30 | 89 | ||
| 48 | 56 | ||
| 50 | 53 | ||
| 59.94/60 | 44 | ||
| 96 | 28 | ||
| 120 | 22 | ||
| 12-bit | 23.98/24 | 100 | |
| 25 | 96 | ||
| 29.97/30 | 80 |
VIEWING & OFFLOADING
Viewing or offloading V-RAW data is handled by the Codex solution. Since data recorded on V-RAW 2.0 Recorder is uncompressed data out of a 4K sensor, V-RAW data can be captured as a clip file using Codex Capture Drive® 2.0 and needs to be de-bayered to preview. Third-party software supporting Codex or V-RAW de-bayering, previewing, or transcoding to intermediate files for dailies or offline editing is also available.
Products
CODEX CAPTURE DRIVE® 2.0
CODEX CAPTURE DRIVE®
2.0 DOCK
CODEX Production Suite
DETAILS OF V-RAW RECORDING & WORKFLOW
GRADING & MASTERING TOOL
V-RAW files (.vrw) created in the off-loading process can be directly loaded and used for grading/mastering in a V-RAW-compatible environment. V-RAW files (.vrw) can be handled even a post environment not compatible with V-RAW by transcoding files to DPX. V-RAW recording is a solution for creators who are eager to maximize flexibility in creation and make the most of the expressiveness of the VariCam 35’s sensor.
| Partner | Product Name | V-RAW Support Version |
|---|---|---|
| Adobe | Premiere Pro CC | v2015 + Plugin*1 |
| Avid | Media Composer | v8.4 + Plugin*1 |
| Assimilate | Scratch / Play | v8.3 |
| Autodesk | Flame family, Smoke | v2016 ext1 + Plugin*1 |
| BlackMagic | DaVinci Resolve Studio | v12.0.1 |
| Codex | Production Suite | v4.0 |
| Colorfront | On-Set Dailies, Transkoder Express Dailies |
v2015 update2 v2015 update1 |
| Digital Vision | NuCoda | v2015.2 |
| Filmlight | Baselight | v4.4m1.7567 |
| Pomfort | Silverstack | v5.1 |
*1 Drastic Media Reactor Plugin v5.04.
Products and versions are confirmed with Partners as of February, 2018.
